A dark mode, dark theme, night mode, or light-on-dark color scheme is a color scheme that uses light-colored text, icons, and graphical user interface elements on a dark background. It is often discussed in terms of computer user interface design and web design. Many modern websites and operating systems offer the user an optional light-on-dark display mode. Some users find dark mode displays more visually appealing, and claim that it can reduce eye strain. Displaying white at full brightness uses roughly six times as much power as pure black on a 2016 Google Pixel, which has an OLED display. However, conventional LED displays may not benefit from reduced power consumption; but if a LED display has the partial dimming features, it still benefits from reduced power consumption. Most modern operating systems support an optional light-on-dark color scheme. == History == Microsoft introduced the high contrast themes in Windows 95. Later, Microsoft introduced a dark theme in the Anniversary Update of Windows 10 in 2016. In 2018, Apple followed in macOS Mojave. In September 2019, iOS 13 and Android 10 both introduced dark modes. Some operating systems provide tools to change the dark mode state automatically at sundown or sunrise. A "prefers-color-scheme" option was created for front-end web developers in 2019, being a CSS property that signals a user's choice for their system to use a light or dark color theme. Firefox and Chromium have optional dark theme for all internal screens. It is also possible for third-party developers to implement their own dark themes. There are also a variety of browser add-ons that can re-theme web sites with dark color schemes, also aligning with system theme. Wikipedia's mobile and desktop versions received a dark mode option in 2024. == Implementation == There is a prefers-color-scheme media query in CSS, to detect if the user has requested light or dark color scheme and serve the requested color scheme. It can be indicated from the user's operating system preference or a user agent. CSS example: JavaScript example: == Energy usage == Light on dark color schemes require less energy to display on OLED displays. This positively impacts battery life and reduces energy consumption. While an OLED will consume around 40% of the power of an LCD displaying an image that is primarily black, it can use more than three times as much power to display an image with a white background, such as a document or web site. This can lead to reduced battery life and higher energy usage unless a light-on-dark color scheme is used. The long-term reduced power usage may also prolong battery life or the useful life of the display and battery. The energy savings that can be achieved using a light-on-dark color scheme are because of how OLED screens work: in an OLED screen, each subpixel generates its own light and it only consumes power when generating light. This is in contrast to how an LCD works: in an LCD, subpixels either block or allow light from an always-on (lit) LED backlight to pass through. "AMOLED Black" color schemes (that use pure black instead of dark gray) do not necessarily save more energy than other light-on-dark color schemes that use dark gray instead of black, as the power consumption on an AMOLED screen decreases proportionately to the average brightness of the displayed pixels. Although it is true that AMOLED black does save more energy than dark gray, the additional energy savings are often negligible; AMOLED black will only give an additional energy saving of less than 1%, for instance, over the dark gray that's used in the dark theme for Google's official Android apps. In November 2018, Google confirmed that dark mode on Android saved battery life. == Web issues == Some argue that a color scheme with light text on a dark background is easier to read on the screen, because the lower overall brightness causes less eyestrain, while others argue to the contrary. Some pages on the web are designed for white backgrounds; Image assets (GIF, PNG, SVG, WOFF, etc) can be used improperly causing visual artifacts if dark mode is forced (instead of designed for) with a plugin like Dark Reader.
Double descent
Double descent in statistics and machine learning is the phenomenon where a model's error rate on the test set initially decreases with the number of parameters, then peaks, then decreases again. This phenomenon has been considered surprising, as it contradicts assumptions about overfitting in classical machine learning. The increase usually occurs near the interpolation threshold, where the number of parameters is the same as the number of training data points (the model is just large enough to fit the training data). Or, more precisely, it is the maximum number of samples on which the model/training procedure achieves approximately on average 0 training error. == History == Early observations of what would later be called double descent in specific models date back to 1989. The term "double descent" was coined by Belkin et. al. in 2019, when the phenomenon gained popularity as a broader concept exhibited by many models. The latter development was prompted by a perceived contradiction between the conventional wisdom that too many parameters in the model result in a significant overfitting error (an extrapolation of the bias–variance tradeoff), and the empirical observations in the 2010s that some modern machine learning techniques tend to perform better with larger models. == Theoretical models == Double descent occurs in linear regression with isotropic Gaussian covariates and isotropic Gaussian noise. A model of double descent at the thermodynamic limit has been analyzed using the replica trick, and the result has been confirmed numerically. A number of works have suggested that double descent can be explained using the concept of effective dimension: While a network may have a large number of parameters, in practice only a subset of those parameters are relevant for generalization performance, as measured by the local Hessian curvature. This explanation is formalized through PAC-Bayes compression-based generalization bounds, which show that less complex models are expected to generalize better under a Solomonoff prior.
Ray tracing (graphics)
In 3D computer graphics, ray tracing is a technique for modeling light transport for use in a wide variety of rendering algorithms for generating digital images. On a spectrum of computational cost and visual fidelity, ray tracing-based rendering techniques, such as ray casting, recursive ray tracing, distribution ray tracing, photon mapping and path tracing, are generally slower and higher fidelity than scanline rendering methods. Thus, ray tracing was first deployed in applications where taking a relatively long time to render could be tolerated, such as still CGI images, and film and television visual effects (VFX), but was less suited to real-time applications such as video games, where speed is critical in rendering each frame. Since 2018, however, hardware acceleration for real-time ray tracing has become standard on new commercial graphics cards, and graphics APIs have followed suit, allowing developers to use hybrid ray tracing and rasterization-based rendering in games and other real-time applications with a lesser hit to frame render times. Ray tracing is capable of simulating a variety of optical effects, such as reflection, refraction, soft shadows, scattering, depth of field, motion blur, caustics, ambient occlusion and dispersion phenomena (such as chromatic aberration). It can also be used to trace the path of sound waves in a similar fashion to light waves, making it a viable option for more immersive sound design in video games by rendering realistic reverberation and echoes. In fact, any physical wave or particle phenomenon with approximately linear motion can be simulated with ray tracing. Ray tracing–based rendering techniques that sample light over a domain typically generate multiple rays and often rely on denoising to reduce the resulting noise. == History == The idea of ray tracing comes from as early as the 16th century, when it was described by Albrecht Dürer, who is credited for its invention. Dürer described multiple techniques for projecting 3-D scenes onto an image plane. Some of these project chosen geometry onto the image plane, as is done with rasterization today. Others determine what geometry is visible along a given ray, as is done with ray tracing. Using a computer for ray tracing to generate shaded pictures was first accomplished by Arthur Appel in 1968. Appel used ray tracing for primary visibility (determining the closest surface to the camera at each image point) by tracing a ray through each point to be shaded into the scene to identify the visible surface. The closest surface intersected by the ray was the visible one. This non-recursive ray tracing-based rendering algorithm is today called "ray casting". His algorithm then traced secondary rays to the light source from each point being shaded to determine whether the point was in shadow or not. Later, in 1971, Goldstein and Nagel of MAGI (Mathematical Applications Group, Inc.) published "3-D Visual Simulation", wherein ray tracing was used to make shaded pictures of solids. At the ray-surface intersection point found, they computed the surface normal and, knowing the position of the light source, computed the brightness of the pixel on the screen. Their publication describes a short (30-second) film "made using the University of Maryland's display hardware outfitted with a 16mm camera. The film showed the helicopter and a simple ground-level gun emplacement. The helicopter was programmed to undergo a series of maneuvers including turns, take-offs, and landings, etc., until it eventually is shot down and crashed." A CDC 6600 computer was used. MAGI produced an animation video called MAGI/SynthaVision Sampler in 1974. Another early instance of ray casting came in 1976, when Scott Roth created a flip book animation in Bob Sproull's computer graphics course at Caltech. The scanned pages are shown as a video in the accompanying image. Roth's computer program noted an edge point at a pixel location if the ray intersected a bounded plane different from that of its neighbors. Of course, a ray could intersect multiple planes in space, but only the surface point closest to the camera was noted as visible. The platform was a DEC PDP-10, a Tektronix storage-tube display, and a printer which would create an image of the display on rolling thermal paper. Roth extended the framework, introduced the term ray casting in the context of computer graphics and solid modeling, and in 1982 published his work while at GM Research Labs. Turner Whitted was the first to show recursive ray tracing for mirror reflection and for refraction through translucent objects, with an angle determined by the solid's index of refraction, and to use ray tracing for anti-aliasing. Whitted also showed ray traced shadows. He produced a recursive ray traced film called The Compleat Angler in 1979 while an engineer at Bell Labs. Whitted's deeply recursive ray tracing algorithm reframed rendering from being primarily a matter of surface visibility determination to being a matter of light transport. His paper inspired a series of subsequent work by others that included distribution ray tracing and finally unbiased path tracing, which provides the rendering equation framework that has allowed computer-generated imagery to be faithful to reality. For decades, global illumination in major films using computer-generated imagery was approximated with additional lights. Ray tracing-based rendering eventually changed that by enabling physically based light transport. Early feature films rendered entirely using path tracing include Monster House (2006), Cloudy with a Chance of Meatballs (2009), and Monsters University (2013). == Algorithm overview == Optical ray tracing describes a method for producing visual images constructed in 3D computer graphics environments, with more photorealism than either ray casting or scanline rendering techniques. It works by tracing a path from an imaginary eye through each pixel in a virtual screen, and calculating the color of the object visible through it. Scenes in ray tracing are described mathematically by a programmer or by a visual artist (normally using intermediary tools). Scenes may also incorporate data from images and models captured by means such as digital photography. Typically, each ray must be tested for intersection with some subset of all the objects in the scene. Once the nearest object has been identified, the algorithm will estimate the incoming light at the point of intersection, examine the material properties of the object, and combine this information to calculate the final color of the pixel. Certain illumination algorithms and reflective or translucent materials may require more rays to be re-cast into the scene. It may at first seem counterintuitive or "backward" to send rays away from the camera, rather than into it (as actual light does in reality), but doing so is many orders of magnitude more efficient. Since the overwhelming majority of light rays from a given light source do not make it directly into the viewer's eye, a "forward" simulation could potentially waste a tremendous amount of computation on light paths that are never recorded. Therefore, the shortcut taken in ray tracing is to presuppose that a given ray intersects the view frame. After either a maximum number of reflections or a ray traveling a certain distance without intersection, the ray ceases to travel and the pixel's value is updated. === Calculate rays for rectangular viewport === On input we have (in calculation we use vector normalization and cross product): E ∈ R 3 {\displaystyle E\in \mathbb {R^{3}} } eye position T ∈ R 3 {\displaystyle T\in \mathbb {R^{3}} } target position θ ∈ [ 0 , π ] {\displaystyle \theta \in [0,\pi ]} field of view - for humans, we can assume ≈ π / 2 rad = 90 ∘ {\displaystyle \approx \pi /2{\text{ rad}}=90^{\circ }} m , k ∈ N {\displaystyle m,k\in \mathbb {N} } numbers of square pixels on viewport vertical and horizontal direction i , j ∈ N , 1 ≤ i ≤ k ∧ 1 ≤ j ≤ m {\displaystyle i,j\in \mathbb {N} ,1\leq i\leq k\land 1\leq j\leq m} numbers of actual pixel v → ∈ R 3 {\displaystyle {\vec {v}}\in \mathbb {R^{3}} } vertical vector which indicates where is up and down, usually v → = [ 0 , 1 , 0 ] {\displaystyle {\vec {v}}=[0,1,0]} - roll component which determine viewport rotation around point C (where the axis of rotation is the ET section) The idea is to find the position of each viewport pixel center P i j {\displaystyle P_{ij}} which allows us to find the line going from eye E {\displaystyle E} through that pixel and finally get the ray described by point E {\displaystyle E} and vector R → i j = P i j − E {\displaystyle {\vec {R}}_{ij}=P_{ij}-E} (or its normalization r → i j {\displaystyle {\vec {r}}_{ij}} ). First we need to find the coordinates of the bottom left viewport pixel P 1 m {\displaystyle P_{1m}} and find the next pixel by making a shift along directions parallel to viewport (vectors b → n {\displaystyle {\vec {b}}_{n
Czekanowski distance
The Czekanowski distance (sometimes shortened as CZD) is a per-pixel quality metric that estimates quality or similarity by measuring differences between pixels. Because it compares vectors with strictly non-negative elements, it is often used to compare colored images, as color values cannot be negative. This different approach has a better correlation with subjective quality assessment than PSNR. == Definition == Androutsos et al. give the Czekanowski coefficient as follows: d z ( i , j ) = 1 − 2 ∑ k = 1 p min ( x i k , x j k ) ∑ k = 1 p ( x i k + x j k ) {\displaystyle d_{z}(i,j)=1-{\frac {2\sum _{k=1}^{p}{\text{min}}(x_{ik},\ x_{jk})}{\sum _{k=1}^{p}(x_{ik}+x_{jk})}}} Where a pixel x i {\displaystyle x_{i}} is being compared to a pixel x j {\displaystyle x_{j}} on the k-th band of color – usually one for each of red, green and blue. For a pixel matrix of size M × N {\displaystyle M\times N} , the Czekanowski coefficient can be used in an arithmetic mean spanning all pixels to calculate the Czekanowski distance as follows: 1 M N ∑ i = 0 M − 1 ∑ j = 0 N − 1 ( 1 − 2 ∑ k = 1 3 min ( A k ( i , j ) , B k ( i , j ) ) ∑ k = 1 3 ( A k ( i , j ) + B k ( i , j ) ) ) {\displaystyle {\frac {1}{MN}}\sum _{i=0}^{M-1}\sum _{j=0}^{N-1}{\begin{pmatrix}1-{\frac {2\sum _{k=1}^{3}{\text{min}}(A_{k}(i,j),\ B_{k}(i,j))}{\sum _{k=1}^{3}(A_{k}(i,j)+B_{k}(i,j))}}\end{pmatrix}}} Where A k ( i , j ) {\displaystyle A_{k}(i,j)} is the (i, j)-th pixel of the k-th band of a color image and, similarly, B k ( i , j ) {\displaystyle B_{k}(i,j)} is the pixel that it is being compared to. == Uses == In the context of image forensics – for example, detecting if an image has been manipulated –, Rocha et al. report the Czekanowski distance is a popular choice for Color Filter Array (CFA) identification.
Film-out
Film-out is the process in the computer graphics, video production and filmmaking disciplines of transferring images or animation from videotape or digital files to a traditional film print. Film-out is a broad term that encompasses the conversion of frame rates, color correction, as well as the actual printing, also called scannior recording. The film-out process is different depending on the regional standard of the master videotape in question – NTSC, PAL, or SECAM – or likewise on the several emerging region-independent formats of high definition video (HD video); thus each type is covered separately, taking into account regional film-out industries, methods and technical considerations. == Live action video == Many modern documentaries and low-budget films are shot on videotape or other digital video media, instead of film stock, and completed as digital video. Video production means substantially lower costs than 16 mm or 35 mm film production on all levels. Until recently, the relatively low cost of video ended when the issue of a theatrical presentation was raised, which required a print for film projection. With the growing presence of digital projection, this is becoming less of a factor. === Standard definition (SD) video === Film-out of standard-definition video – or any source that has an incompatible frame rate – is the up-conversion of video media to film for theatrical viewing. The video-to-film conversion process consists of two major steps: first, the conversion of video into digital film frames which are then stored on a computer or on HD videotape; and secondly, the printing of these digital film frames onto actual film. To understand these two steps, it is important to understand how video and film differ. Film (sound film, at least) has remained unchanged for almost a century and creates the illusion of moving images through the rapid projection of still images, frames, upon a screen, typically 24 per second. Traditional interlaced SD video has no real frame rate, (though the term frame is applied to video, it has a different meaning). Instead, video consists of a very fast succession of horizontal lines that continually cascade down the television screen – streaming top to bottom, before jumping back to the top and then streaming down to the bottom again, repeatedly, almost 60 alternating screen-fulls every second for NTSC, or exactly 50 such screen-fulls per second for PAL and SECAM. Since visual movement in video is infused in this continuous cascade of scan lines, there is no discrete image or real frame that can be identified at any one time. Therefore, when transferring video to film, it is necessary to invent individual film frames, 24 for every second of elapsed time. The bulk of the work done by a film-out company is this first step, creating film frames out of the stream of interlaced video. Each company employs its own (often proprietary) technology for turning interlaced video into high-resolution digital video files of 24 discrete images every second, called 24 progressive video or 24p. The technology must filter out all the visually unappealing artifacting that results from the inherent mismatch between video and film movement. Moreover, the conversion process usually requires human intervention at every edit point of a video program, so that each type of scene can be calibrated for maximum visual quality. The use of archival footage in video especially calls for extra attention. Step two, the scanning to film, is the rote part of the process. This is the mechanical step where lasers print each of the newly created frames of the 24p video, stored on computer files or HD videotape, onto rolls of film. Most companies that do film-out, do all the stages of the process themselves for a lump sum. The job includes converting interlaced video into 24p and often a color correction session – (calibrating the image for theatrical projection), before scanning to physical film, (possibly followed by color correction of the film print made from the digital intermediary) – is offered. At the very least, film-out can be understood as the process of converting interlaced video to 24p and then scanning it to film. ==== NTSC video ==== NTSC is the most challenging of the formats when it comes to standards conversion and, specifically, converting to film prints. NTSC runs at the approximate rate of 29.97 video frames (consisting of two interlaced screen-fulls of scan lines, called fields, per frame) per second. In this way, NTSC resolves actual live action movement at almost – but not quite – 60 alternating half-resolution images every second. Because of this 29.97 rate, no direct correlation to film frames at 24 frames per second can be achieved. NTSC is hardest to reconcile with film, thus motivating its own unique processes. ==== PAL and SECAM video ==== PAL and SECAM run at 25 interlaced video frames per second, which can be slowed down or frame-dropped, then deinterlaced, to correlate frame for frame with film running at 24 actual frames per second. PAL and SECAM are less complex and demanding than NTSC for film-out. PAL and SECAM conversions do agitate, though, with the unpleasant choice between slowing down video (and audio pitch, noticeably) by four percent, from 25 to 24 frames per second, in order to maintain a 1:1 frame match, slightly changing the rhythm and feel of the program; or maintaining original speed by periodically dropping frames, thereby creating jerkiness and possible loss of vital detail in fast-moving action or precise edits. === High definition (HD) digital video === High definition digital video can be shot at a variety of frame rates, including 29.97 interlaced (like NTSC) or progressive; or 25 interlaced (like PAL) or progressive; or even 24-progressive (just like film). HD, if shot in 24-progressive, scans nearly perfectly to film without the need for a frame or field conversion process. Other issues remain though, based on the different resolutions, color spaces, and compression schemes that exist in the high-definition video world. == Computer graphics and animation == Artists working with CGI-Computer-generated imagery animation computers create pictures frame by frame. Once the finished product is done, the frames are outputted, normally in a DPX file. These picture data files can then be put on to film using a film recorder for film out. SGI computers started the high-end CGI-Computer-generated imagery animation systems, but with faster computers and the growth of Linux-based systems, many others are on the market now. Movies fully rendered and animated in CGI such as Toy Story, and Antz utilize the film-out method to produce 35mm copies for archival and release prints. Most CGI work is done in 2K Display resolution files (about the size of QXGA) and then output to the Film-out device for creation of 35 mm elements. With 4K Display resolution digital intermediates on the rise, newer types of film-out recorders are being developed to accept 4k resolution files. A 2K movie requires a Storage Area Network storage several terabytes in size to be properly stored and played out. Computer graphics files are handled the same way but in single frames and may use DPX, TIFF or other file formats. == Digital intermediates == Film-out-recording is the last step of digital intermediate workflow. DPX files that were scanned on a motion picture film scanner are stored on a storage area network (often abbreviated as SAN). The scanned DPX footage is edited and composited-FX on workstations, then mastered back on film. Film restoration is also done this way. A "film intermediate" is an analog variation of a digital intermediate, where a project shot on digital video is printed onto film stock and transferred back to digital video to emulate film. The term was coined after it was used on the Oscar-winning 2012 short film "Curfew". The process was also used on the films Dune (2021) and The Batman (2022). == Images for graphic design and print industries == The days of newspapers and magazines shooting 35mm film are almost gone. Digital cameras can now shoot all the images needed, storing them as files (e.g. JPEG, DPX or another format) that are readily edited prior to use. Once the final copy is approved, it can be filmed out for publishing. Digital stills are not the only way to get pictures used in the graphic design and print industries. Film scanners and computer graphics programs are also common sources for graphic design and print industries. == Types of devices == The following devices are used in film-out processes: CRT recorder. Camera and a special TV display Kinescope – early type Electronic Video Recording or EVR – early type EBR Electron Beam Film Recorder 16 mm by 3M Laser film recorder, like Kodak's high-end Lightning II recorder and Arri's Arrilaser. DLP Film recorder, like Cinevation's real-time Cinevator. == History == Lately it has become possible to transfer video images, inclu
Digital video effect
Digital video effects (DVEs) are visual effects that provide comprehensive live video image manipulation, in the same form as optical printer effects in film. DVEs differ from standard video switcher effects (often referred to as analog effects) such as wipes or dissolves, in that they deal primarily with resizing, distortion or movement of the image. Modern video switchers often contain internal DVE functionality. Modern DVE devices are incorporated in high-end broadcast video switchers. Early examples of DVE devices found in the broadcast post-production industry include the Ampex Digital Optics (ADO), Quantel DPE-5000, Vital Squeezoom, NEC E-Flex and the Abekas A5x series of DVEs. By 1988, Grass Valley Group caught up with the competition with their Kaleidoscope, which integrated ADO-type effects with their widely used line of broadcast switching gear. DVEs are used by the broadcast television industry in live television production environments like television studios and outside broadcasts. They are commonly used in video post-production.
IDMS
The Integrated Database Management System (IDMS) is a network model (CODASYL) database management system for mainframes. It was first developed at BFGoodrich and later marketed by Cullinane Database Systems (renamed Cullinet in 1983). Since 1989 the product has been owned by Computer Associates (now CA Technologies), who renamed it Advantage CA-IDMS and later simply to CA IDMS. In 2018 Broadcom acquired CA Technologies, renaming it back to IDMS. == History == The roots of IDMS go back to the pioneering database management system called Integrated Data Store (IDS), developed at General Electric by a team led by Charles Bachman and first released in 1964. In the early 1960s IDS was taken from its original form, by the computer group of the BFGoodrich Chemical Division, and re-written in a language called Intermediate System Language (ISL). ISL was designed as a portable system programming language able to produce code for a variety of target machines. Since ISL was actually written in ISL, it was able to be ported to other machine architectures with relative ease, and then to produce code that would execute on them. The Chemical Division computer group had given some thought to selling copies of IDMS to other companies, but was told by management that they were not in the software products business. Eventually, a deal was struck with John Cullinane to buy the rights and market the product. Because Cullinane was required to remit royalties back to B.F. Goodrich, all add-on products were listed and billed as separate products – even if they were mandatory for the core IDMS product to work. This sometimes confused customers. The original platforms were the GE 235 computer and GE DATANET-30 message switching computer: later the product was ported to IBM mainframes and to DEC and ICL hardware. The IBM-ported version runs on IBM mainframe systems (System/360, System/370, System/390, zSeries, System z9). In the mid-1980s, it was claimed that some 2,500 IDMS licenses had been sold. Users included the Strategic Air Command, Ford of Canada, Ford of Europe, Jaguar Cars, Clarks Shoes UK, Axa/PPP, MAPFRE, Royal Insurance, Tesco, Manulife, Hudson's Bay Company, Cleveland Clinic, Bank of Canada, General Electric, Aetna and BT in the UK. A version for use on the Digital Equipment Corporation PDP-11 series of computers was sold to DEC and was marketed as DBMS-11. In 1976 the source code was licensed to ICL, who ported the software to run on their 2900 series mainframes, and subsequently also on the older 1900 range. ICL continued development of the software independently of Cullinane, selling the original ported product under the name ICL 2900 IDMS and an enhanced version as IDMSX. In this form it was used by many large UK users, an example being the Pay-As-You-Earn system operated by Inland Revenue. Many of these IDMSX systems for UK Government were still running in 2013. In the early to mid-1980s, relational database management systems started to become more popular, encouraged by increasing hardware power and the move to minicomputers and client–server architecture. Relational databases offered improved development productivity over CODASYL systems, and the traditional objections based on poor performance were slowly diminishing. Cullinet attempted to continue competing against IBM's DB2 and other relational databases by developing a relational front-end and a range of productivity tools. These included Automatic System Facility (ASF), which made use of a pre-existing IDMS feature called LRF (Logical Record Facility). ASF was a fill-in-the-blanks database generator that would also develop a mini-application to maintain the tables. It is difficult to judge whether such features may have been successful in extending the selling life of the product, but they made little impact in the long term. Those users who stayed with IDMS were primarily interested in its high performance, not in its relational capabilities. It was widely recognized (helped by a high-profile campaign by E. F. Codd, the father of the relational model) that there was a significant difference between a relational database and a network database with a relational veneer. In 1989 Computer Associates continued after Cullinet acquisition with the development and released Release 12.0 with full SQL in 1992–93. CA Technologies continued to market and support the CA IDMS and enhanced IDMS in subsequent releases by TCP/IP support, two phase commit support, XML publishing, zIIP specialty processor support, Web-enabled access in combination with CA IDMS Server, SQL Option and GUI database administration via CA IDMS Visual DBA tool. CA-IDMS systems are today still running businesses worldwide. Many customers have opted to web-enable their applications via the CA-IDMS SQL Option which is part of CA Technologies' Dual Database Strategy. == Integrated Data Dictionary == One of the sophisticated features of IDMS was its built-in Integrated data dictionary (IDD). The IDD was primarily developed to maintain database definitions. It was itself an IDMS database. DBAs (database administrators) and other users interfaced with the IDD using a language called Data Dictionary Definition Language (DDDL). IDD was also used to store definitions and code for other products in the IDMS family such as ADS/Online and IDMS-DC. IDD's power was that it was extensible and could be used to create definitions of just about anything. Some companies used it to develop in-house documentation. == Overview == === Logical Data Model === The data model offered to users is the CODASYL network model. The main structuring concepts in this model are records and sets. Records essentially follow the COBOL pattern, consisting of fields of different types: this allows complex internal structure such as repeating items and repeating groups. The most distinctive structuring concept in the Codasyl model is the set. Not to be confused with a mathematical set, a Codasyl set represents a one-to-many relationship between records: one owner, many members. The fact that a record can be a member in many different sets is the key factor that distinguishes the network model from the earlier hierarchical model. As with records, each set belongs to a named set type (different set types model different logical relationships). Sets are in fact ordered, and the sequence of records in a set can be used to convey information. A record can participate as an owner and member of any number of sets. Records have identity, the identity being represented by a value known as a database key. In IDMS, as in most other Codasyl implementations, the database key is directly related to the physical address of the record on disk. Database keys are also used as pointers to implement sets in the form of linked lists and trees. This close correspondence between the logical model and the physical implementation (which is not a strictly necessary part of the Codasyl model, but was a characteristic of all successful implementations) is responsible for the efficiency of database retrieval, but also makes operations such as database loading and restructuring rather expensive. Records can be accessed directly by database key, by following set relationships, or by direct access using key values. Initially the only direct access was through hashing, a mechanism known in the Codasyl model as CALC access. In IDMS, CALC access is implemented through an internal set, linking all records that share the same hash value to an owner record that occupies the first few bytes of every disk page. In subsequent years, some versions of IDMS added the ability to access records using BTree-like indexes. === Storage === IDMS organizes its databases as a series of files. These files are mapped and pre-formatted into so-called areas. The areas are subdivided into pages which correspond to physical blocks on the disk. The database records are stored within these blocks. The DBA allocates a fixed number of pages in a file for each area. The DBA then defines which records are to be stored in each area, and details of how they are to be stored. IDMS intersperses special space-allocation pages throughout the database. These pages are used to keep track of the free space available in each page in the database. To reduce I/O requirements, the free space is only tracked for all pages when the free space for the area falls below 30%. Four methods are available for storing records in an IDMS database: Direct, Sequential, CALC, and VIA. The Fujitsu/ICL IDMSX version extends this with two more methods, Page Direct, and Random. In direct mode the target database key is specified by the user and is stored as close as possible to that DB key, with the actual DB key on which the record is stored being returned to the application program. Sequential placement (not to be confused with indexed sequential), simply places each new record at the end of the area. This option is rarely used. CALC uses a hashing algo
